Manufacturer
Whirlpool Replacement Parts

Model Number
GB2FHDXWQ04

Description
Refrigerator

Interactive Exploded View

Interactive Exploded View - view assemblies diagrams and click the part you need

CategoryPart NumberDescriptionDemandAvailability
Cleaner31462A
Whirlpool Accessories,cleaner,stainless SteelNo
Bracket, Flange, BladeWPW10284684
Whirlpool Adapter,slide (Left Hand)YIn Stock In stock
25.95
Bracket, Flange, BladeWPW10284685
Whirlpool Adapter,slide (Right Hand)
Schematic Location: 21
YIn Stock In stock
25.95
WPW10378255
Whirlpool Arm,shut Off
Schematic Location: 6
Ships in 30 days
40.95
Ice Maker, Ice Maker AssemblyW10884390
Whirlpool Assembly,icemaker (Complete)
Schematic Location: 100
Skill level: - Easy fix less than an hour
YNo
72.95
Pump, MotorWPW10281342
Whirlpool Assembly,module And Motor
Schematic Location: 20
No
WPW10300025
Whirlpool Assembly,mold And Heater
Schematic Location: 9
YIn Stock In stock
82.95
Axle, Roller, Shaft WheelWPW10515763
Whirlpool Assembly,roller (Left Hand)
Schematic Location: 19
YIn Stock In stock
49.95
Axle, Roller, Shaft WheelWPW10515762
Whirlpool Assembly,roller (Right Hand)
Skill level: - Easy fix less than an hour
YIn Stock In stock
48.95
Axle, Roller, Shaft Wheel67006434
Whirlpool Axle,roller
Schematic Location: 30
YShips in 30 days
8.95
PlateW10480110
Whirlpool Basepan
Schematic Location: 3
Ships in 30 days
67.95
BasketWPW10503183
Whirlpool Basket,freezer (Lower)
Schematic Location: 5
YIn Stock In stock
123.95
BasketWPW10348238
Whirlpool Basket,freezer (Upper)
Schematic Location: 4
YIn Stock In stock
103.95
CondensorWP12825803
Whirlpool Blade,fan
Schematic Location: 2
Skill level: - Easy fix less than an hour
YIn Stock In stock
43.95
Fan BladeWP2169142
Whirlpool Blade,fan
Schematic Location: 24
Skill level: - Easy fix less than an hour
YIn Stock In stock
24.95
WP12227303WD
Whirlpool Brace,crisper Cover
Schematic Location: 17
YIn Stock In stock
52.95
DrawerWPW10330994
Whirlpool Bracket,door (Left Hand)
Schematic Location: 13
YShips in 30 days
56.95
Bracket, Flange, BladeWPW10330995
Whirlpool Bracket,door (Right Hand)YIn Stock In stock
102.95
Bracket, Flange, BladeWP2256087
Whirlpool Bracket,ice Maker
Schematic Location: 1
YIn Stock In stock
39.95
Leg, Foot, CasterWPW10141622
Whirlpool Brake,roller
Schematic Location: 6
YIn Stock In stock
8.95
Door,Remote Control DoorWPW10371194
Whirlpool Bucket,medium
Schematic Location: 5
Skill level: - Fast and very easy fix
YIn Stock In stock
50.95
Light8009
Whirlpool Bulb,light
Schematic Location: 9
Skill level: - Fast and very easy fix
YIn Stock In stock
5.95
Light4396822
Whirlpool Bulb-light
Schematic Location: 9
YIn Stock In stock
13.95
CapacitorWPW10662129
Whirlpool Capacitor
Schematic Location: 29
Skill level: - Easy fix less than an hour
YIn Stock In stock
41.95
AdhesiveWP4317852
Whirlpool Cement,alumilastic (1 1/4 Oz.)YShips in 48 days
36.95
ClampM0108107
Whirlpool Clamp,tube
Schematic Location: 27
No
Wire10526702
Whirlpool Clamp,wire
Schematic Location: 3
No
ClampW10281329
Whirlpool Clip,drier
Schematic Location: 34
Ships in 30 days
9.95
Clip13058002
Whirlpool Clip,evaporator Motor
Schematic Location: 15
Ships in 30 days
15.95
Clip10428101
Whirlpool Clip,heater
Schematic Location: 25
Ships in 30 days
50.95
ClipWPM0114003
Whirlpool Clip,speed
Schematic Location: 19
YShips in 30 days
9.95
ClipWP628379
Whirlpool Clip,thermal Fuse
Schematic Location: 14
Ships in 30 days
9.95
WP67003639
Whirlpool Closure,door (Black)YIn Stock In stock
38.95
WP67003638
Whirlpool Closure,door (White)
Schematic Location: 15
YIn Stock In stock
8.95
Compressor - Sealed SystemW10507884
Whirlpool Compressor
Schematic Location: 28
Skill level: - Hard fix - you can do It
YIn Stock In stock
385.95
CondensorWPW10346420
Whirlpool Condenser
Schematic Location: 18
Ships in 30 days
109.95
ControlWPW10503278
Whirlpool Control,electronic
Schematic Location: 5
Skill level: - Easy fix less than an hour
YIn Stock In stock
133.95
WP503695
Whirlpool Cork,sealerYIn Stock In stock
48.95
Cover,Cap67003485
Whirlpool Cover,corner (Black)YShips in 30 days
20.95
Cover,Cap12587703W
Whirlpool Cover,corner (White)
Schematic Location: 17
Ships in 30 days
20.95
Cover,CapWP12806701
Whirlpool Cover,damper
Schematic Location: 13
Ships in 30 days
46.95
Cover,CapW10308415
Whirlpool Cover,evaporator
Schematic Location: 11
Ships in 30 days
98.95
Cover,CapW10377174
Whirlpool Cover,front
Schematic Location: 7
Ships in 30 days
39.95
Cover,Cap67001012
Whirlpool Cover,hinge (Black)YIn Stock In stock
38.95
Cover,Cap67001014
Whirlpool Cover,hinge (White)
Schematic Location: 10
Ships in 30 days
20.95
Cover,CapWP67003897
Whirlpool Cover,light
Schematic Location: 7
No
Cover,CapWP67003924
Whirlpool Cover,thermistor
Schematic Location: 31
YIn Stock In stock
8.95
Cover,CapWPW10210979
Whirlpool Cover,unit
Schematic Location: 21
Ships in 30 days
69.95
Cover,CapW10208592
Whirlpool Cover,valve
Schematic Location: 5
Ships in 30 days
44.95
Cover,Cap12726003
Whirlpool Cover,water Line
Schematic Location: 13
In Stock In stock
14.95
Bracket, Flange, BladeWPW10280608
Whirlpool Cradle,basket (Left Hand)In Stock In stock
43.95
Bracket, Flange, BladeWPW10280613
Whirlpool Cradle,basket (Right Hand)
Schematic Location: 18
In Stock In stock
43.95
CupW10410073
Whirlpool Cup,water Fill
Schematic Location: 10
Ships in 30 days
35.95
72032
Whirlpool Customer Touch-up Material (Black)YIn Stock In stock
10.95
Washer72017
Whirlpool Customer Touch-up Material (White)
Schematic Location: NI
Skill level: - Fast and very easy fix
YIn Stock In stock
10.95
12225602
Whirlpool Dam (Left Hand)No
12225702
Whirlpool Dam (Right Hand)
Schematic Location: 23
YNo
ControlWPW10196393
Whirlpool Damper,control
Schematic Location: 15
Skill level: - Easy fix less than an hour
YIn Stock In stock
79.95
Compressor - Sealed SystemWPW10448874
Whirlpool Device,start
Schematic Location: 12
Skill level: - Easy fix less than an hour
YIn Stock In stock
67.95
Deflector & ChuteW10157765
Whirlpool Diverter,air
Schematic Location: 34
Ships in 11 days
39.95
W10847995
Whirlpool Divider,basket (Lower)
Schematic Location: 10
YShips in 30 days
39.95
W10311695
Whirlpool Divider,basket (Upper)
Schematic Location: 22
Ships in 30 days
25.95
W10241046
Whirlpool Divider,basket (Upper)
Schematic Location: 9
Ships in 30 days
23.95
Door,Remote Control DoorWP67003637
Whirlpool Door,dairy
Schematic Location: 3
YIn Stock In stock
51.95
Door,Remote Control Door13109214BQ
Whirlpool Door,freezer (Black)Ships in 30 days
440.95
Door,Remote Control Door13109401BQ
Whirlpool Door,refrigerator (Black)Ships in 30 days
456.95
Compressor - Sealed SystemWPW10143759
Whirlpool Drier
Schematic Location: 27
Skill level: - Hard fix - you can do It
YIn Stock In stock
25.95
W10318914
Whirlpool Ejector
Schematic Location: 11
Ships in 30 days
24.95
Pipe, Tube, Hose, FittingWPW10137519
Whirlpool Elbow,fill Tube
Schematic Location: 23
In Stock In stock
48.95
GuideW10258249
Whirlpool Energy GuideNo
EvaporatorWPW10317013
Whirlpool Evaporator
Schematic Location: 22
No
ShieldW10277466
Whirlpool Foil,housing
Schematic Location: 10
No
DrawerWPW10568041
Whirlpool Frame-crisper
Schematic Location: 18
Skill level: - Fast and very easy fix
YIn Stock In stock
74.95
Door,Remote Control Door13109214WQ
Whirlpool Freezer Door (W/ Insulation) (White)
Schematic Location: 1
Ships in 30 days
440.95
FunnelW10815413
Whirlpool Funnel,drain
Schematic Location: 27
YIn Stock In stock
38.95
Gasket , SealB5759655
Whirlpool Gasket
Schematic Location: 4
Ships in 30 days
15.95
Gasket , SealWPW10436248
Whirlpool Gasket,door (Black)
Schematic Location: 8
YIn Stock In stock
142.95
Door,Remote Control DoorWPW10436250
Whirlpool Gasket,door (Black)
Schematic Location: 3
Skill level: - Fast and very easy fix
YIn Stock In stock
125.95
Gasket , SealW10443313
Whirlpool Gasket,door (White)YIn Stock In stock
126.95
Gasket , SealW10571962
Whirlpool Gasket,door (White)No
Gasket , SealWPB8381501
Whirlpool Gasket,drain
Schematic Location: 29
In Stock In stock
8.95
Gasket , SealA3189395
Whirlpool Gasket,foam
Schematic Location: 20
No
Gasket , Seal67003731
Whirlpool Gasket,foam
Schematic Location: 2
No
Drawer12002497
Whirlpool Gear
Schematic Location: 3
Skill level: - Easy fix less than an hour
YIn Stock In stock
17.95
Gear, WheelWPW10474716
Whirlpool Gear (Left Hand)
Schematic Location: 26
YIn Stock In stock
20.95
Gear, WheelWPW10474715
Whirlpool Gear (Right Hand)YShips in 30 days
20.95
DrawerWP67006878
Whirlpool Glass,crisper
Schematic Location: 19
Skill level: - Fast and very easy fix
YIn Stock In stock
109.95
DrawerWP67001054
Whirlpool Glide,deli (Left Hand)
Schematic Location: 13
Skill level: - Fast and very easy fix
YIn Stock In stock
8.95
WP67001053
Whirlpool Glide,deli (Right Hand)
Schematic Location: 14
YIn Stock In stock
8.95
GreaseWP542638
Whirlpool Grease,silicone (1/2 Oz.)YIn Stock In stock
32.95
WPW10175909
Whirlpool Grille,freezer Air
Schematic Location: 22
YIn Stock In stock
40.95
WPW10534162
Whirlpool Grille,toe (Black)YIn Stock In stock
50.95
WPW10534161
Whirlpool Grille,toe (White)
Schematic Location: 22
YIn Stock In stock
49.95
WPW10169124
Whirlpool Grommet,compressor
Schematic Location: 17
Ships in 30 days
8.95
WPW10137529
Whirlpool Grommet,condenser
Schematic Location: 37
Ships in 30 days
8.95
2319835
Whirlpool Grommet,condenser
Schematic Location: 5
No
W10150583
Whirlpool Grommet,fan Motor
Schematic Location: 25
YShips in 30 days
38.95
Bracket, Flange, Blade67005874
Whirlpool Guide,fill Tube
Schematic Location: 7
No
HandleWPW10222984K
Whirlpool Handle,door
Schematic Location: 2
YIn Stock In stock
92.95
HandleWPW10222985
Whirlpool Handle,door (Black)No
WireWPW10422363
Whirlpool Harness,controls (Refrigerator)
Schematic Location: NI
YShips in 30 days
55.95
WireWPW10290745
Whirlpool Harness,evaporator (Includes Heater)
Schematic Location: 7
YNo
99.95
WireWPW10458985
Whirlpool Harness,ice Maker
Schematic Location: 18
YIn Stock In stock
49.95
WireWPW10234024
Whirlpool Harness,unit (Includes Power Cord)
Schematic Location: 26
In Stock In stock
146.95
WP12729128
Whirlpool Heater,defrost
Schematic Location: 10
YIn Stock In stock
69.95
HingeWP12607104ED
Whirlpool Hinge,center (Black)
Schematic Location: 15
Skill level: - Fast and very easy fix
YIn Stock In stock
49.95
HingeWP12607103WD
Whirlpool Hinge,center (White)Ships in 30 days
59.95
HingeWP12566606ED
Whirlpool Hinge,top (Right Hand)
Schematic Location: 16
Skill level: - Fast and very easy fix
Ships in 30 days
26.95
HousingW10443023
Whirlpool Housing,light
Schematic Location: 8
Ships in 30 days
46.95
Insert67003900
Whirlpool Insert,damper Cover
Schematic Location: 11
Ships in 30 days
8.95
Pipe, Tube, Hose, FittingWPA3223101
Whirlpool Insert,tube
Schematic Location: 8
Skill level: - Easy fix less than an hour
YShips in 30 days
8.95
Insulation12820505
Whirlpool Insulation
Schematic Location: 26
Ships in 30 days
48.95
InsulationWP13012402
Whirlpool Insulation,damper
Schematic Location: 14
Ships in 30 days
40.95
Terminal833938
Whirlpool Kit,terminal ConnectorYIn Stock In stock
8.95
W10273463
Whirlpool Ladder,center
Schematic Location: 20
Ships in 30 days
20.95
W10251969
Whirlpool Ladder,side
Schematic Location: 21
Ships in 30 days
21.95
HandleW10149389
Whirlpool Lift,bail Arm
Schematic Location: 24
YShips in 30 days
39.95
212643
Whirlpool Miscellaneous,sealer,gum (4 Feet)YIn Stock In stock
39.95
WP505587
Whirlpool Miscellaneous,sealer,mastic (1 Qt)YIn Stock In stock
60.95
Tape479502
Whirlpool Miscellaneous,tape,vinyl (3/4 X 108")No
HousingWPW10464769
Whirlpool Module,control
Schematic Location: 4
YIn Stock In stock
45.95
HousingW10464757
Whirlpool Module,light
Schematic Location: 2
Ships in 30 days
47.95
HousingWPW10277025
Whirlpool Module,light
Schematic Location: 14
Ships in 30 days
55.95
Pump, MotorWP13062901
Whirlpool Motor,evaporator
Schematic Location: 26
No
CondensorWPW10239053
Whirlpool Motor,fan
Schematic Location: 24
Skill level: - Easy fix less than an hour
No
Bracket, Flange, BladeW10348259
Whirlpool Mount,gear (Left Hand)Ships in 30 days
42.95
Bracket, Flange, BladeW10348260
Whirlpool Mount,gear (Right Hand)
Schematic Location: 25
Ships in 30 days
42.95
PlateWPW10393265
Whirlpool Nameplate (Grey)In Stock In stock
45.95
PlateWPW10391355
Whirlpool Nameplate (White)
Schematic Location: 12
Ships in 30 days
43.95
W10207256
Whirlpool Overlay
Schematic Location: 3
Ships in 30 days
40.95
799344
Whirlpool Paint,bulk (1 Qt. White)Ships in 30 days
81.95
285006
Whirlpool Paint,pressurized Spray (12 Oz. Enamel,black)YIn Stock In stock
29.95
Auto Primer350942
Whirlpool Paint,pressurized Spray (12 Oz. White Primer)YIn Stock In stock
33.95
350930
Whirlpool Paint,pressurized Spray (12 Oz. White)YIn Stock In stock
15.95
DrawerWP67002633
Whirlpool Pan,crisper
Schematic Location: 16
Skill level: - Fast and very easy fix
YIn Stock In stock
78.95
WP67001314
Whirlpool Pan,deli
Schematic Location: 12
YIn Stock In stock
75.95
WPW10655367
Whirlpool Pan,drain
Schematic Location: 8
YIn Stock In stock
57.95
Ice Maker ComponentsWPW10171529
Whirlpool Pan,ice
Schematic Location: 25
YIn Stock In stock
59.95
PinWP67006642
Whirlpool Pin,center Hinge
Schematic Location: 7
YShips in 30 days
8.95
PlugM0310343
Whirlpool Plug,button (White)
Schematic Location: 17
Ships in 30 days
9.95
Knob, Dial, ButtonWP12246608
Whirlpool Plug-button (Black)
Schematic Location: 6
YIn Stock In stock
8.95
Knob, Dial, ButtonWP67001130
Whirlpool Plug-button (White)In Stock In stock
8.95
DrawerWPW10671238
Whirlpool Rail,center Crisper
Schematic Location: 1
Skill level: - Fast and very easy fix
YIn Stock In stock
48.95
RailWPW10516603
Whirlpool Rail,side (Left Hand)
Schematic Location: 35
No
RailWPW10516602
Whirlpool Rail,side (Right Hand)No
Door,Remote Control Door13109401WQ
Whirlpool Refrigerator Door (W/ Insulation) (White)
Schematic Location: 1
In Stock In stock
456.95
Trim67001019
Whirlpool Retainer,door
Schematic Location: 13
YIn Stock In stock
59.95
Axle, Roller, Shaft WheelWP67005149
Whirlpool Roller
Schematic Location: 35
YIn Stock In stock
20.95
ScrewWP489464
Whirlpool Screw
Schematic Location: 17
YIn Stock In stock
8.95
ScrewW10001240
Whirlpool Screw
Schematic Location: 4
Ships in 30 days
11.95
ScrewWP489355
Whirlpool Screw
Schematic Location: 15
Skill level: - Fast and very easy fix
In Stock In stock
18.95
Screw67006425
Whirlpool Screw
Schematic Location: 11
YIn Stock In stock
5.95
ScrewW10215666
Whirlpool Screw
Schematic Location: 7
Ships in 30 days
11.95
ScrewWP33001882
Whirlpool Screw
Schematic Location: 21
Ships in 30 days
36.95
ScrewW10216919
Whirlpool Screw
Schematic Location: 9
Ships in 30 days
9.95
Screw12992301
Whirlpool Screw
Schematic Location: 1
Ships in 30 days
24.95
ScrewWP400021-1
Whirlpool Screw
Schematic Location: 12
YIn Stock In stock
9.95
ScrewWPW10288153
Whirlpool Screw
Schematic Location: 4
YIn Stock In stock
6.95
ScrewWP489474
Whirlpool Screw
Schematic Location: 32
YShips in 30 days
6.95
ScrewWP98165
Whirlpool Screw
Schematic Location: 30
YIn Stock In stock
5.95
Screw67006564
Whirlpool Screw
Schematic Location: 20
In Stock In stock
5.95
ScrewWP489349
Whirlpool Screw
Schematic Location: 14
Skill level: - Fast and very easy fix
In Stock In stock
5.95
ScrewWP8281196
Whirlpool Screw
Schematic Location: 9
Skill level: - Fast and very easy fix
YIn Stock In stock
8.95
WPM0500703
Whirlpool Seal
Schematic Location: 28
In Stock In stock
9.95
Shaft12812905WD
Whirlpool Shaft,rack
Schematic Location: 23
No
Shaft12812902WD
Whirlpool Shaft,rack
Schematic Location: 5
No
Shelf Support ComponentsWP12463310
Whirlpool Shelf,glide Out
Schematic Location: 6
No
Shelf Support ComponentsWP12463509
Whirlpool Shelf,stationary
Schematic Location: 3
No
WPW10189184
Whirlpool Shroud,condenser Fan
Schematic Location: 31
YIn Stock In stock
47.95
WPW10167023
Whirlpool Shroud,evaporator Fan
Schematic Location: 23
Ships in 30 days
42.95
DrawerWPW10120018
Whirlpool Slide,door
Schematic Location: 19
Skill level: - Easy fix less than an hour
YIn Stock In stock
128.95
SlideWP67005864
Whirlpool Slide,humidity Control
Schematic Location: 8
YIn Stock In stock
8.95
SocketWPW10134764
Whirlpool Socket,light
Schematic Location: 6
No
Door,Remote Control DoorWP67003780
Whirlpool Stop,door (Black)YIn Stock In stock
5.95
Door,Remote Control DoorWP67003779
Whirlpool Stop,door (White)
Schematic Location: 11
YShips in 30 days
5.95
ClipW10174384
Whirlpool Strap,bale
Schematic Location: 11
Ships in 30 days
15.95
WPW10122563
Whirlpool Stripper,ice
Schematic Location: 12
YIn Stock In stock
40.95
Pipe, Tube, Hose, FittingW10216614
Whirlpool Sweep,water Valve
Schematic Location: 8
No
SwitchWPC3680310
Whirlpool Switch,light
Schematic Location: 6
Skill level: - Easy fix less than an hour
No
Switch12002646
Whirlpool Switch,light
Schematic Location: 16
Skill level: - Easy fix less than an hour
No
W10475386
Whirlpool Tech SheetNo
Sensor, Thermistor, ThermostatWP627985
Whirlpool Thermostat
Schematic Location: 15
Skill level: - Easy fix less than an hour
YIn Stock In stock
51.95
WP1117510
Whirlpool Torx Screw Wrench,torx Key
Skill level: - Medium fix difficulty
YNo
Tray, Support , Ice Maker TrayWP67001279
Whirlpool Tray,dairy
Schematic Location: 4
YIn Stock In stock
48.95
Tray, Support , Ice Maker TrayWPW10292802
Whirlpool Tray,drip
Schematic Location: 20
YShips in 30 days
69.95
TrimWPW10231482
Whirlpool Trim,crisper
Schematic Location: 2
Ships in 30 days
50.95
Pipe, Tube, Hose, FittingWPW10233570
Whirlpool Tube,discharge
Schematic Location: 6
YShips in 30 days
52.95
Pipe, Tube, Hose, FittingW10619951
Whirlpool Tube,drain
Schematic Location: 24
YIn Stock In stock
40.95
Pipe, Tube, Hose, FittingWPB5705333SP
Whirlpool Tubing,plastic
Schematic Location: 2
No
GuideW10366204SP
Whirlpool Use & Care Guide
Schematic Location: 1
No
Valve, Float AssemblyWP978025
Whirlpool Valve,accessYIn Stock In stock
35.95
Valve, Float Assembly978027
Whirlpool Valve,accessYIn Stock In stock
41.95
Valve, Float Assembly978030
Whirlpool Valve,accessIn Stock In stock
43.95
Valve, Float Assembly978029
Whirlpool Valve,accessIn Stock In stock
41.95
Valve, Float Assembly978026
Whirlpool Valve,accessYIn Stock In stock
44.95
Valve, Float Assembly876764
Whirlpool Valve,accessYIn Stock In stock
39.95
Valve, Float AssemblyWPW10498976
Whirlpool Valve,water
Schematic Location: 5
YIn Stock In stock
76.95
Whirlpool Corporation is the number one major appliance manufacturer in the world, and includes brands such as Whirlpool, KitchenAid, Maytag, Consul, Brastemp, Amana, Bauknecht, Jenn-Air, Indesit, among others. The Whirlpool Corporation is an American multinational manufacturer and marketer of home appliances, headquartered in Benton Charter Township, Michigan, United States, near Benton Harbor, Michigan. In many Whirlpool appliances, remarkable sense and adapt technology responds to the needs of your clothes, your meals and your foods. By adapting to each situation, intuitive sensors make key refinementsprecisely adjusting water levels for the best clean possible or measuring moisture content for better baking. So your fabrics look newer longer, meals cook more evenly, and foods stay cool and flavorful.
