ED2KHAXVQ01 Whirlpool Replacement Parts

Manufacturer

Model Number
ED2KHAXVQ01

Description
Side-by-side Refrigerator

Owners Manual

Interactive Exploded View

Parts Prediction

Tell us what's wrong with your Whirlpool Side-by-side Refrigerator, and we can predict what parts you need to fix it.

Clicking sound

Door Sweating

Door won't open or close

Freezer not defrosting

Freezer section too warm

Freezer too cold

Ice maker dispenses too little ice

Ice maker not making ice

Ice maker won't dispense ice

Refrigerator and Freezer are too warm

Refrigerator runs too long

Refrigerator too cold

Refrigerator too warm

Will not start

Parts List

Category	Part Number	Description	Demand
	W10332806	Whirlpool Air Baffle Schematic Location: 31
Diffuser	WPW10151375	Whirlpool Air Diffuser Assembly Schematic Location: 9
Cover,Cap	2152019	Whirlpool Air Diffuser Cover Schematic Location: 10
Duct, Vent	2312009	Whirlpool Air Duct Freezer Schematic Location: 5
	2317247	Whirlpool Auger
Sensor, Thermistor, Thermostat	WPW10225581	Whirlpool Bi-metal, Defrost Schematic Location: 4 Skill level: - Easy fix less than an hour	Y
Blade	2257020	Whirlpool Blade, Fixed Schematic Location: 9	Y
Blade	W10278731	Whirlpool Blade, Rotary Schematic Location: 13
Blade	W10278732	Whirlpool Blade, Rotary Schematic Location: 10
Blade	W10278733	Whirlpool Blade, Rotary Schematic Location: 7
	2317239	Whirlpool Block, Blade Schematic Location: 11
Insulation	2260519	Whirlpool Block, Housing Support Schematic Location: 19
Hinge	W10251418	Whirlpool Bottom Hinge (Fc) Schematic Location: 40
Hinge	8201707	Whirlpool Bottom Hinge (Rc) Schematic Location: 16	Y
Cover,Cap	W10133000	Whirlpool Box Cover Schematic Location: 39
	WP2256085	Whirlpool Bracket Retainer Schematic Location: 8
Board	W10677671	Whirlpool Bracket, Control Schematic Location: 15
Bracket, Flange, Blade	WP2198641	Whirlpool Bracket, Cover Schematic Location: 3 Skill level: - Fast and very easy fix	Y
Bracket, Flange, Blade	WP2304673	Whirlpool Bracket, Dispenser Schematic Location: 20	Y
Bracket, Flange, Blade	WP2206629B	Whirlpool Bracket, Door Stop (Chrome) Schematic Location: 11	Y
Bracket, Flange, Blade	WPW10131253	Whirlpool Bracket, Mounting Schematic Location: 19	Y
Knob, Dial, Button	WP2260503B	Whirlpool Button, Water Filter (Biscuit) Schematic Location: 24	Y
Knob, Dial, Button	2260503MG	Whirlpool Button, Water Filter (Midn/aght Grey) Schematic Location: 24
Knob, Dial, Button	2260503W	Whirlpool Button, Water Filter (White) Schematic Location: 24	Y
Filter	2260502T	Whirlpool Cap, Water Filter (Biscuit) Schematic Location: 17
Cover,Cap	WP2260518B	Whirlpool Cap, Water Filter (Black) Schematic Location: 17 Skill level: - Fast and very easy fix	Y
Cover,Cap	WP2260518MG	Whirlpool Cap, Water Filter (Midn/aght Grey) Schematic Location: 17	Y
Cover,Cap	WP2260518W	Whirlpool Cap, Water Filter (White) Schematic Location: 17 Skill level: - Fast and very easy fix	Y
Capacitor	WPW10662129	Whirlpool Capacitor (Production) Schematic Location: 13 Skill level: - Easy fix less than an hour	Y
Adhesive	WP4317852	Whirlpool Cement, Alumilastic (1 1/4 Oz.)	Y
Clamp	549193	Whirlpool Clamp, Service Cord Schematic Location: 36
Clip	489396	Whirlpool Clip Schematic Location: 34
Clip	W11661170	Whirlpool Clip Schematic Location: 5
Clip	WP2255411	Whirlpool Clip Schematic Location: 8	Y
Clip	WP2161324	Whirlpool Clip (2) Schematic Location: 27	Y
Clip	2215823	Whirlpool Clip, Air Duct (2) Schematic Location: 12	Y
Clip	W10683556	Whirlpool Clip, Condenser(2) Schematic Location: 12
Clip	WP628379	Whirlpool Clip, Fuse Schematic Location: 2	Y
Clip	WP2155013	Whirlpool Clip, Grille Schematic Location: 6	Y
Clip	2155547	Whirlpool Clip, Heat Shield Schematic Location: 32
Clip	1115375	Whirlpool Clip, Wiring Schematic Location: 19
Clip	WP1115374	Whirlpool Clip, Wiring Schematic Location: 18
Ice Maker, Ice Maker Assembly	WPW10190961	Whirlpool Complete Icemaker Assembly Schematic Location: 100	Y
Compressor - Sealed System	W10233961	Whirlpool Compressor (Includes Items 10, 13, 21, & 29) (Also Order 876 Schematic Location: 28 Skill level: - Hard fix - you can do It	Y
Condensor	W10211163	Whirlpool Condenser Assembly Schematic Location: 3
	2161308	Whirlpool Connecting Rod Schematic Location: 20
	2161307	Whirlpool Connecting Rod (Short) Schematic Location: 25
Board	WP2321748	Whirlpool Control Board, Lcd Schematic Location: 23
	2181737	Whirlpool Control Box Schematic Location: 1
	2326982	Whirlpool Control Box Schematic Location: 38
Wire	2310533	Whirlpool Control Box Harness Schematic Location: 17
Panel	W11115203	Whirlpool Control Panel	Y
	WP503695	Whirlpool Cork, Sealer (1/4 Pound)	Y
Coupling	W11629923	Whirlpool Coupling Schematic Location: 16	Y
Cover,Cap	WPW10289690	Whirlpool Cover Schematic Location: 7	Y
Cover,Cap	2222862	Whirlpool Cover Schematic Location: 29
Cover,Cap	2150331	Whirlpool Cover, Conduit Schematic Location: 11
Cover,Cap	2317248	Whirlpool Cover, Crusher Schematic Location: 6	Y
Cover,Cap	WP2198587	Whirlpool Cover, Emitter Schematic Location: 13 Skill level: - Fast and very easy fix	Y
Cover,Cap	W10207507	Whirlpool Cover, Evaporator (Includes No.9) Schematic Location: 15
Door,Remote Control Door	W10180062	Whirlpool Cover, Ice Maker Schematic Location: 18
Cover,Cap	W10508993	Whirlpool Cover, Meat Pan Schematic Location: 8 Skill level: - Fast and very easy fix	Y
Cover,Cap	W10173569	Whirlpool Cover, Receiver Schematic Location: 26	Y
Cover,Cap	WP2188756	Whirlpool Cover, Un/at Schematic Location: 32	Y
Pan	WP2188656	Whirlpool Crisper Pan Schematic Location: 10 Skill level: - Fast and very easy fix	Y
	WPW10176384	Whirlpool Crusher Bin Schematic Location: 2	Y
Cup	WPW10130299	Whirlpool Cup, Shelf (16) Schematic Location: 7	Y
Cup	WPW10272168	Whirlpool Cup, Water Fill Schematic Location: 10
Deflector & Chute	2179350	Whirlpool Deflector Schematic Location: 6
Duct, Vent	2313359	Whirlpool Diffuser, Air Duct Schematic Location: 3
Motor,Ice Maker Motor	W10822606	Whirlpool Dispenser, Motor Schematic Location: 28 Skill level: - Easy fix less than an hour	Y
	2317250	Whirlpool Divider-chamber Schematic Location: 25
Bin	WPW10321304	Whirlpool Door Bin (3) Schematic Location: 4 Skill level: - Fast and very easy fix	Y
Door,Remote Control Door	WPW10329686	Whirlpool Door Closer (Rc) Lower Cam (2) Schematic Location: 38 Skill level: - Easy fix less than an hour	Y
Door,Remote Control Door	WP2223751	Whirlpool Door Closer, (Fc) Schematic Location: 41 Skill level: - Easy fix less than an hour	Y
Door,Remote Control Door	WP2182179	Whirlpool Door Closer, Upper Cam Schematic Location: 9 Skill level: - Fast and very easy fix	Y
Gasket , Seal	2159080	Whirlpool Door Gasket, Magnetic (Black) Schematic Location: 8	Y
Gasket , Seal	2159081	Whirlpool Door Gasket, Magnetic (Black) Schematic Location: 5	Y
Gasket , Seal	W10136733	Whirlpool Door Gasket, Magnetic (Grey) Schematic Location: 8	Y
Gasket , Seal	W10136732	Whirlpool Door Gasket, Magnetic (Grey) Schematic Location: 5	Y
Gasket , Seal	2159072	Whirlpool Door Gasket, Magnetic (Mist Beige) Schematic Location: 8	Y
Gasket , Seal	2159073	Whirlpool Door Gasket, Magnetic (Mist Beige) Schematic Location: 5	Y
Door,Remote Control Door	WP2180353	Whirlpool Door Mechan/asm Assembly Schematic Location: 7 Skill level: - Easy fix less than an hour	Y
Door,Remote Control Door	WP2256101	Whirlpool Door, Compartment Schematic Location: 2	Y
Pipe, Tube, Hose, Fitting	W11566763	Whirlpool Drain Fitting Schematic Location: 30	Y
Compressor - Sealed System	WPW10143759	Whirlpool Drier (Production) Schematic Location: 21 Skill level: - Hard fix - you can do It	Y
Shaft	WP2188917	Whirlpool Drive Shaft Schematic Location: 26	Y
	626753	Whirlpool Ejector Schematic Location: 11
Board	WPW10259855	Whirlpool Elec. Control Schematic Location: 40	Y
Timer	4388932	Whirlpool Electron/ac Control Schematic Location: 6 Skill level: - Easy fix less than an hour	Y
Bracket, Flange, Blade	2322488	Whirlpool Enclosure, Motor Schematic Location: 27	Y
Guide	2326836	Whirlpool Energy Label Schematic Location: 1
Escutcheon	W10175967	Whirlpool Escutcheon, Meat Pan Control Schematic Location: 2
Evaporator	WP2188822	Whirlpool Evaporator Schematic Location: 16	Y
Extension	W11512417	Whirlpool Extension Tube Schematic Location: 31	Y
Blade	WP2169142	Whirlpool Fan Blade Schematic Location: 8 Skill level: - Easy fix less than an hour	Y
	WP2176759	Whirlpool Fan Grommet (2) Schematic Location: 10	Y
Motor,Ice Maker Motor	WP2315549	Whirlpool Fan Motor Schematic Location: 7 Skill level: - Easy fix less than an hour	Y
	W11254898	Whirlpool Fan Scroll Schematic Location: 1
Blade	W10156818	Whirlpool Fan, Blade Schematic Location: 2 Skill level: - Fast and very easy fix	Y
Motor,Ice Maker Motor	WP2188874	Whirlpool Fan, Motor Bracket Schematic Location: 25 Skill level: - Easy fix less than an hour	Y
Fastener	489391	Whirlpool Fastener, Push-on Schematic Location: 21
	W10283958	Whirlpool Filler Wrapper (Biscuit) Schematic Location: 21
	W11252732	Whirlpool Filler, Wrapper (Black) Schematic Location: 21
	W10851579	Whirlpool Filler, Wrapper (Grey) Schematic Location: 21
	WPW10283959	Whirlpool Filler, Wrapper (White) Schematic Location: 21	Y
Valve, Float Assembly	W10822681	Whirlpool Filter Valve Asm Schematic Location: 5	Y
Pipe, Tube, Hose, Fitting	WPW10140630	Whirlpool Fitting/water Tube Schematic Location: 3
Cover,Cap	WP2198633	Whirlpool Flipper Schematic Location: 25 Skill level: - Fast and very easy fix	Y
Bin	WP2309758	Whirlpool Freezer Bin Schematic Location: 6	Y
Door,Remote Control Door	L2327199B	Whirlpool Freezer Door (Includes Item 8 And Dispenser Front Parts) Schematic Location: 1
Door,Remote Control Door	L2327199W	Whirlpool Freezer Door (Includes Item 8 And Dispenser Front Parts) Schematic Location: 1
Door,Remote Control Door	L2327199T	Whirlpool Freezer Door (Includes Item 8 And Dispenser Front Parts) Schematic Location: 1
Door,Remote Control Door	L2327199S	Whirlpool Freezer Door (Includes Item 8 And Dispenser Front Parts) Schematic Location: 1
Door,Remote Control Door	L2327199LA	Whirlpool Freezer Door (Includes Item 8 And Dispenser Front Parts) Schematic Location: 1
Door,Remote Control Door	L2327199L	Whirlpool Freezer Door (Includes Item 8 And Dispenser Front Parts) Schematic Location: 1
Cover,Cap	W10157644	Whirlpool Front Cover Assembly (Biscuit) Schematic Location: 18
Cover,Cap	W10172004	Whirlpool Front Cover Assembly (N/ackel) Schematic Location: 18
Cover,Cap	W10157643	Whirlpool Front Cover Assembly (Stan/aless) Schematic Location: 18
Cover,Cap	WPW10242637	Whirlpool Front Cover, Control Box Schematic Location: 22
Axle, Roller, Shaft Wheel	4386774	Whirlpool Front Roller (2) Schematic Location: 2	Y
Gasket , Seal	4388500	Whirlpool Gasket Schematic Location: 14	Y
Gasket , Seal	2305571	Whirlpool Gasket Schematic Location: 22
Gasket , Seal	WP2304241	Whirlpool Gasket, Evaporator Cover (2) Schematic Location: 9	Y
Gasket , Seal	WP2155789	Whirlpool Gasket, Fan Scroll Schematic Location: 13	Y
Glass Shelf	W10864399	Whirlpool Glass, Cover Schematic Location: 2 Skill level: - Fast and very easy fix	Y
Grease	WP542638	Whirlpool Grease, Silicone (1/2 Oz.)	Y
Grille Kickplate	WPW10184880	Whirlpool Grille (Midn/aght Grey) Schematic Location: 22 Skill level: - Fast and very easy fix
	WPW10283955	Whirlpool Grille (White) Schematic Location: 22	Y
	WP2206671T	Whirlpool Grille, Overflow (Biscuit) Schematic Location: 9	Y
	WP2206671B	Whirlpool Grille, Overflow (Black) Schematic Location: 9	Y
	W10171992	Whirlpool Grille, Overflow (N/ackel) Schematic Location: 9
	WP2206671W	Whirlpool Grille, Overflow (White) Schematic Location: 9	Y
	937252	Whirlpool Grommet (4)
	876811	Whirlpool Grommet (4) ((Production))
Kit	4388295	Whirlpool Grommet (4) (Production) Schematic Location: 29	Y
	2172906	Whirlpool Grommet, Light Bar Schematic Location: 11
Guide	WP2180224	Whirlpool Guide, Ice Schematic Location: 12 Skill level: - Easy fix less than an hour	Y
Handle	WPW10127763	Whirlpool Handle (Includes No.3) (Biscuit) Schematic Location: 6
Handle	WPW10127762	Whirlpool Handle (Includes No.3) (Black) Schematic Location: 6	Y
Handle	W10273555	Whirlpool Handle (Includes No.3) (Stan/aless/satina) Schematic Location: 6
Handle	WPW10127761K	Whirlpool Handle (Includes No.3) (White) Schematic Location: 6	Y
Wire	2310237	Whirlpool Harness, Fan Evaporator (Includes No.4) Schematic Location: 12	Y
Wire	WPW10309401	Whirlpool Harness, Wiring Schematic Location: 18
Shield	2172931	Whirlpool Heat Shield Schematic Location: 26
Shield	WPW10194474	Whirlpool Heat Shield Schematic Location: 20
	WP2323197	Whirlpool Heater, Defrost Schematic Location: 26	Y
Cover,Cap	W10138584	Whirlpool Hinge Cover (Apollo Grey) Schematic Location: 34
Cover,Cap	W10138579	Whirlpool Hinge Cover (Apollo Grey) Schematic Location: 15
Cover,Cap	W10138583	Whirlpool Hinge Cover (Biscuit) Schematic Location: 34
Cover,Cap	W10138578	Whirlpool Hinge Cover (Biscuit) Schematic Location: 15
Cover,Cap	W10138582	Whirlpool Hinge Cover (Black) Schematic Location: 34
Cover,Cap	W10138577	Whirlpool Hinge Cover (Black) Schematic Location: 15
Cover,Cap	W10331627	Whirlpool Hinge Cover (White) Schematic Location: 34
Cover,Cap	W10331623	Whirlpool Hinge Cover (White) Schematic Location: 15
Hinge	WP2203770	Whirlpool Hinge, Top (Fc) Schematic Location: 12	Y
Hinge	WP2203771	Whirlpool Hinge, Top (Rc) Schematic Location: 13	Y
Holder	WP2188919	Whirlpool Holder Schematic Location: 22	Y
Knob, Dial, Button	940014	Whirlpool Hole Plug Schematic Location: 27
Control	WP2179343	Whirlpool Housing, Humidity Control Schematic Location: 14	Y
Housing	WPW10121138	Whirlpool Housing, Water Filter Schematic Location: 8 Skill level: - Easy fix less than an hour	Y
	WP2317246	Whirlpool Ice Bin Schematic Location: 1
Ice Maker Components	WPW10204457	Whirlpool Ice Container (Complete) Schematic Location: 100
	W10297245	Whirlpool Ice Striper Schematic Location: 12	Y
	W10180407	Whirlpool Instruction Sheet, Door Removal Schematic Location: 1
	799833	Whirlpool Kit, Evaporator Repair (Aluminum Epoxy)
Terminal	833938	Whirlpool Kit, Terminal Connector	Y
Latch	2317274	Whirlpool Latch, Bin Schematic Location: 19
Lens	WP2198643	Whirlpool Lens Schematic Location: 11
Lever	W10155161	Whirlpool Lever, Ice Dispenser (Apollo Grey) Schematic Location: 11
	W10152855	Whirlpool Lever, Ice Dispenser (Biscuit) Schematic Location: 11	Y
	WPW10152854	Whirlpool Lever, Ice Dispenser (Black) Schematic Location: 11	Y
	WPW10152853	Whirlpool Lever, Ice Dispenser (White) Schematic Location: 11	Y
	W10127772	Whirlpool Lever, Water Dispenser (Apollo Grey) Schematic Location: 16	Y
	W10152860	Whirlpool Lever, Water Dispenser (Biscuit) Schematic Location: 16	Y
	WPW10152859	Whirlpool Lever, Water Dispenser (Black) Schematic Location: 16	Y
	WPW10152858	Whirlpool Lever, Water Dispenser (White) Schematic Location: 16	Y
Light	2179921	Whirlpool Light Bar (Fc) Schematic Location: 23
Light	2179920	Whirlpool Light Bar (Rc) Schematic Location: 13
Light	W11679940	Whirlpool Light Bulb	Y
Light	8009	Whirlpool Light Bulb Schematic Location: 15 Skill level: - Fast and very easy fix	Y
Lens	2212376	Whirlpool Light Lens Schematic Location: 8
Lens	W11239891	Whirlpool Light Lens Schematic Location: 5	Y
Socket	4387478	Whirlpool Light Socket Schematic Location: 22	Y
Switch	WP2149705	Whirlpool Light Switch Schematic Location: 4 Skill level: - Easy fix less than an hour	Y
Louver	8201651	Whirlpool Louver Schematic Location: 4	Y
Pan	WP2188664	Whirlpool Meat Pan Schematic Location: 11 Skill level: - Fast and very easy fix	Y
Filter	W10823377	Whirlpool Mechan/asm Delay Schematic Location: 8 Skill level: - Easy fix less than an hour	Y
	628370	Whirlpool Modular Icemaker Service Sheet Schematic Location: 1
Motor,Ice Maker Motor	8201515	Whirlpool Module Assembly Schematic Location: 20	Y
	WPW10122550	Whirlpool Mold & Heater Assembly (Also Order 542638 Schematic Location: 9	Y
Plate	WP2213265	Whirlpool Nameplate Schematic Location: 12	Y
	W11629974	Whirlpool P.c. Board, Receiver Schematic Location: 9	Y
	799344	Whirlpool Paint, Bulk (1 Qt. White)
	4392900	Whirlpool Paint, Bulk (1 Qt.) (Biscuit)
	786032	Whirlpool Paint, Bulk (1 Qt.) (Black (Uncut))
	799340	Whirlpool Paint, Bulk (1 Qt.) (Black)
	8171358	Whirlpool Paint, Bulk (1 Qt.) (Graphite`)
	350930	Whirlpool Paint, Pressurized Spray (12 Oz. White)	Y
	4392901	Whirlpool Paint, Pressurized Spray (12 Oz.) (Biscuit)	Y
	8171357	Whirlpool Paint, Pressurized Spray (12 Oz.) (Graphite)	Y
Auto Primer	350942	Whirlpool Paint, Pressurized Spray (12 Oz.) (Primer, White)	Y
	285006	Whirlpool Paint, Pressurized Spray 12 Oz.) (Black)	Y
	72032	Whirlpool Paint, Touch-up (1/2Oz. Black)	Y
Washer	72017	Whirlpool Paint, Touch-up (1/2Oz. White) Skill level: - Fast and very easy fix	Y
	4392899	Whirlpool Paint, Touch-up (1/2Oz.) (Biscuit) Skill level: - Fast and very easy fix	Y
	WP80051	Whirlpool Paint, Touch-up (1/2Oz.) (Graphite)	Y
Pin	WP2196195	Whirlpool Pin Schematic Location: 5	Y
Pin	WP2198634	Whirlpool Pin Schematic Location: 15
	2161306	Whirlpool Pivot Arm Schematic Location: 14
Cooking Plate	WP2304249	Whirlpool Plate, Screw Schematic Location: 7	Y
Door,Remote Control Door	L2263189T	Whirlpool Refrigerator Door (Includes Item 5) (Biscuit) Schematic Location: 1
Door,Remote Control Door	L2263189B	Whirlpool Refrigerator Door (Includes Item 5) (Black) Schematic Location: 1
Door,Remote Control Door	L2219033LA	Whirlpool Refrigerator Door (Includes Item 5) (Monochromatic) Schematic Location: 1
Door,Remote Control Door	L2219033L	Whirlpool Refrigerator Door (Includes Item 5) (Stainless Vcm) Schematic Location: 1
Door,Remote Control Door	L2219033S	Whirlpool Refrigerator Door (Includes Item 5) (Stainless) Schematic Location: 1
Door,Remote Control Door	L2263189W	Whirlpool Refrigerator Door (Includes Item 5) (White) Schematic Location: 1
Tank	WPW10276792	Whirlpool Reservoir Schematic Location: 14 Skill level: - Easy fix less than an hour	Y
	WP2155590	Whirlpool Retainer, Fan Motor Schematic Location: 2	Y
Clip	WP2194719	Whirlpool Retainer, Levers Schematic Location: 3 Skill level: - Fast and very easy fix	Y
Clip	WP2315522	Whirlpool Retainer, Thermostat Schematic Location: 14	Y
Pin	489229	Whirlpool Roll Pin Schematic Location: 12
Axle, Roller, Shaft Wheel	WPW10250570	Whirlpool Roller (Rear) (2) Schematic Location: 4	Y
Screw	WPW10141645	Whirlpool Screw	Y
Screw	489136	Whirlpool Screw Schematic Location: 21
Screw	WP681249	Whirlpool Screw Schematic Location: 17	Y
Screw	8533917	Whirlpool Screw Schematic Location: 16
Screw	627068	Whirlpool Screw Schematic Location: 9
Screw	4389654	Whirlpool Screw Schematic Location: 11
Screw	W11544659	Whirlpool Screw Schematic Location: 36
Screw	W11693756	Whirlpool Screw Schematic Location: 9	Y
Screw	WP8533993	Whirlpool Screw Schematic Location: 6
Screw	WP3400906	Whirlpool Screw Schematic Location: 17	Y
Screw	WP3196557	Whirlpool Screw Schematic Location: 2	Y
Screw	WP3400012	Whirlpool Screw Schematic Location: 15	Y
Screw	WP8533988	Whirlpool Screw Schematic Location: 3	Y
Screw	WP8281163	Whirlpool Screw Schematic Location: 21	Y
Screw	WP3400065	Whirlpool Screw Schematic Location: 18	Y
Screw	WP8281164	Whirlpool Screw Schematic Location: 17	Y
Screw	WPW10142283	Whirlpool Screw Schematic Location: 24	Y
Screw	WP489478	Whirlpool Screw Schematic Location: 20	Y
Screw	WP3400806	Whirlpool Screw Schematic Location: 16	Y
Screw	WP3-24004-109	Whirlpool Screw Schematic Location: 13	Y
Screw	W10759522	Whirlpool Screw Schematic Location: 12	Y
Screw	798639	Whirlpool Screw Schematic Location: 7
Screw	WP488729	Whirlpool Screw Schematic Location: 37 Skill level: - Fast and very easy fix	Y
Screw	WP8281227	Whirlpool Screw Schematic Location: 35	Y
Screw	WP489464	Whirlpool Screw Schematic Location: 27	Y
Screw	WP488488	Whirlpool Screw Schematic Location: 26
Screw	W10853301	Whirlpool Screw Schematic Location: 20
Screw	WP489128	Whirlpool Screw Schematic Location: 14	Y
Screw	WP489427	Whirlpool Screw Schematic Location: 5	Y
Screw	W10850698	Whirlpool Screw Schematic Location: 3
Screw	WPW10141625	Whirlpool Screw (2) Schematic Location: 8
Screw	489392	Whirlpool Screw (2) Schematic Location: 7
Screw	WP489483	Whirlpool Screw (2) Schematic Location: 39 Skill level: - Fast and very easy fix	Y
Screw	W10856122	Whirlpool Screw (2) Schematic Location: 25	Y
Screw	WP489500	Whirlpool Screw (2) Schematic Location: 10	Y
Screw	WP489497	Whirlpool Screw (4) Schematic Location: 18 Skill level: - Fast and very easy fix	Y
Screw	489340	Whirlpool Screw (5) Schematic Location: 30
Screw	2006254	Whirlpool Screw, Board Schematic Location: 24
Screw	WPW10288153	Whirlpool Screw, Mounting Schematic Location: 13	Y
Dispenser	WP2198628	Whirlpool Seal Schematic Location: 24 Skill level: - Fast and very easy fix	Y
	212643	Whirlpool Sealer, Gum (4 Feet)	Y
	WP505587	Whirlpool Sealer, Mastic (1 Qt)	Y
Wire	W10205540	Whirlpool Service & Wiring Sheet
Glass Shelf	WPW10276348	Whirlpool Shelf Assembly, Spillguard Schematic Location: 19 Skill level: - Fast and very easy fix	Y
Glass Shelf	WPW10318952	Whirlpool Shelf Wire Schematic Location: 10	Y
Glass Shelf	WPW10276341	Whirlpool Shelf, Snack Pan Schematic Location: 1 Skill level: - Fast and very easy fix	Y
Glass Shelf	WPW10318960	Whirlpool Shelf, Wire Schematic Location: 5 Skill level: - Fast and very easy fix	Y
Glass Shelf	WPW10318953	Whirlpool Shelf, Wire Schematic Location: 2	Y
Shield	2303234	Whirlpool Shield, Wiring Schematic Location: 4
	WP2209697	Whirlpool Shim Schematic Location: 9	Y
Sleeve	W11661094	Whirlpool Sleeve Schematic Location: 8
Sleeve	WP2315559	Whirlpool Sleeve. Coupling Schematic Location: 30	Y
Slide	2182757	Whirlpool Slide Meat Pan Control Schematic Location: 3
Slide	2181741	Whirlpool Slide, Air Control Schematic Location: 10
Slide	WP2179342	Whirlpool Slide, Humidity Control Schematic Location: 9	Y
Slide	2212321	Whirlpool Slide, Ice Maker Mounting Schematic Location: 19	Y
Slide	2315398	Whirlpool Slide, Ice Maker Shut Off Schematic Location: 27
Slide	2161466	Whirlpool Slide, Thermostat Schematic Location: 12	Y
Pan	WP2309517	Whirlpool Snack Pan Schematic Location: 17	Y
Spacer	WP1119005	Whirlpool Spacer, Step (2) Schematic Location: 8	Y
Spacer	WP1119007	Whirlpool Spacer, Step (20) Schematic Location: 5	Y
Spacer	WP625834	Whirlpool Spacer, Switch (2) Schematic Location: 13
Spring	WP2198635	Whirlpool Spring Schematic Location: 14 Skill level: - Easy fix less than an hour	Y
Spring	WP2198608	Whirlpool Spring, Latch Schematic Location: 20 Skill level: - Easy fix less than an hour	Y
Spring	WPW10224328	Whirlpool Spring, Torsion Schematic Location: 4	Y
Washer	489203	Whirlpool Spring, Washer Schematic Location: 8
Compressor - Sealed System	WPW10189190	Whirlpool Start Device Combination Relay & Overload (Production) Schematic Location: 10 Skill level: - Medium fix difficulty	Y
Clip	WP2195051	Whirlpool Strain Relief Schematic Location: 19	Y
Wire	WPW10339879	Whirlpool Strap Schematic Location: 37	Y
Glass Shelf	WP2196483	Whirlpool Stud Assembly Schematic Location: 15 Skill level: - Fast and very easy fix	Y
Glass Shelf	W11223328	Whirlpool Stud Assembly Schematic Location: 12 Skill level: - Fast and very easy fix	Y
Housing	WP2195914	Whirlpool Support Schematic Location: 13	Y
	4388358	Whirlpool Support, R.s Schematic Location: 16	Y
	WP2162361	Whirlpool Switch (2) Schematic Location: 14	Y
Switch	W11457217	Whirlpool Switch, Rocker Arm Schematic Location: 16	Y
Tape	W11238399	Whirlpool Tape, Vinyl (3/4 X 108")
Sensor, Thermistor, Thermostat	WP2315562	Whirlpool Thermostat Schematic Location: 5 Skill level: - Easy fix less than an hour	Y
Sensor, Thermistor, Thermostat	WP627985	Whirlpool Thermostat (Also Order 542369 Cement Alumilastic) Schematic Location: 15 Skill level: - Easy fix less than an hour	Y
	WP2182181	Whirlpool Thimble-top Schematic Location: 7	Y
	WP1117510	Whirlpool Torx Key Skill level: - Medium fix difficulty	Y
Pan	WPW10614158	Whirlpool Tray, Evaporator Schematic Location: 19 Skill level: - Fast and very easy fix	Y
Trim	WPW10307490	Whirlpool Trim, Door Shelf Schematic Location: 9 Skill level: - Fast and very easy fix	Y
Trim	WP2179243	Whirlpool Trim, Handle Schematic Location: 18	Y
Trim	WP2179234	Whirlpool Trim, Meat Pan Schematic Location: 7	Y
Trim	WP2156022	Whirlpool Trivet Schematic Location: 14	Y
Trim	WP2156021	Whirlpool Trivet (3) Schematic Location: 6	Y
Sensor, Thermistor, Thermostat	WP2196003	Whirlpool Tube Barrier, Thermostat Schematic Location: 2	Y
Clamp	WP488366	Whirlpool Tube Clip Schematic Location: 6
Pipe, Tube, Hose, Fitting	W10210787	Whirlpool Tube Suction Schematic Location: 11
Pipe, Tube, Hose, Fitting	W10274306	Whirlpool Tube, Condenser To Heat Loop Schematic Location: 14
Pipe, Tube, Hose, Fitting	8201597	Whirlpool Tube, Filter Inlet Schematic Location: 28 Skill level: - Fast and very easy fix	Y
Pipe, Tube, Hose, Fitting	W11496481	Whirlpool Tube, Filter Outlet Schematic Location: 29	Y
Connector	WPW10334458	Whirlpool Un/aon Schematic Location: 1	Y
Cover,Cap	2304898	Whirlpool Un/at Cover, Bottom Schematic Location: 33
Frame	2304903	Whirlpool Un/at Mounting Frame Schematic Location: 23
Rail	W10207512	Whirlpool Un/at Mounting Rail Schematic Location: 35
Wire	2310425	Whirlpool Un/at, Harness (Includes Power Cord) Schematic Location: 24
Guide	W10167096	Whirlpool Use & Care Guide
Valve, Float Assembly	978028	Whirlpool Valve, Access (1/2``)
Valve, Float Assembly	WP978025	Whirlpool Valve, Access (1/4")	Y
Valve, Float Assembly	876764	Whirlpool Valve, Access (3/16")	Y
Valve, Float Assembly	978030	Whirlpool Valve, Access (3/4")	Y
Valve, Float Assembly	978027	Whirlpool Valve, Access (3/8")	Y
Valve, Float Assembly	978026	Whirlpool Valve, Access (5/16")	Y
Valve, Float Assembly	978029	Whirlpool Valve, Access (5/8")	Y
Washer	W10856867	Whirlpool Washer Schematic Location: 4
Washer	WP2198661	Whirlpool Washer, Coupling Schematic Location: 15 Skill level: - Fast and very easy fix	Y
Washer	WP489235	Whirlpool Washer, Plain Schematic Location: 14	Y
Filter	EDR3RXD1	Whirlpool Water Filter Schematic Location: 11 Skill level: - Fast and very easy fix	Y
Pipe, Tube, Hose, Fitting	8201537	Whirlpool Water Fitting Assembly (Includes Water Tube) Schematic Location: 10	Y
Pipe, Tube, Hose, Fitting	WPW10350006	Whirlpool Water Tube Skill level: - Easy fix less than an hour	Y
	2175513	Whirlpool Window Schematic Location: 24
Wiper Blade	2317243	Whirlpool Wiper Schematic Location: 23	Y

Videos

Cleaning refrigerator condenser coils

How to Level your Refrigerator and Doors

How to remove refrigerator doors

Refrigerator Shelf Adjustment video

About Whirlpool

Whirlpool Corporation is the number one major appliance manufacturer in the world, and includes brands such as Whirlpool, KitchenAid, Maytag, Consul, Brastemp, Amana, Bauknecht, Jenn-Air, Indesit, among others. The Whirlpool Corporation is an American multinational manufacturer and marketer of home appliances, headquartered in Benton Charter Township, Michigan, United States, near Benton Harbor, Michigan. In many Whirlpool appliances, remarkable sense and adapt technology responds to the needs of your clothes, your meals and your foods. By adapting to each situation, intuitive sensors make key refinementsprecisely adjusting water levels for the best clean possible or measuring moisture content for better baking. So your fabrics look newer longer, meals cook more evenly, and foods stay cool and flavorful.

ED2KHAXVQ01 Whirlpool Side-by-side Refrigerator Replacement Parts

Parts Prediction

Parts List

Videos

About Whirlpool

Get 15% Off Your Next Order!

Contact Info

My Account
