WRX988SIBW00

Description
Whirlpool Bottom-mount Refrigerator

Interactive Exploded View

Interactive Exploded View - view assemblies diagrams and click the part you need

CategoryPart NumberDescriptionDemand
Adaptor, ChargersW10667416
Whirlpool Adapter
Adaptor, ChargersWPW10635022
Whirlpool Adapter, Icebox
Schematic Location: 30
Y
DrawerW10850332
Whirlpool Adapter, Upper Pan (Left)
Schematic Location: 14
Skill level: - Fast and very easy fix
Y
Bracket, Flange, BladeW10858092
Whirlpool Adapter,upper Pan (Right)
Schematic Location: 14
Y
DispenserWPW10577864
Whirlpool Assembly Seperator
Schematic Location: 5
Y
W10830496
Whirlpool Assembly, Air Tower
Schematic Location: 41
Y
Pump, MotorW10846539
Whirlpool Assembly, Blower
Schematic Location: 21
Skill level: - Easy fix less than an hour
Y
Bracket, Flange, BladeW10625067
Whirlpool Assembly, Bracket (Left)
Schematic Location: 5
Y
DrawerW10625068
Whirlpool Assembly, Bracket (Right)
Schematic Location: 5
Skill level: - Easy fix less than an hour
Y
W10858802
Whirlpool Assembly, Center Pan
Schematic Location: 15
Y
EvaporatorW11116006
Whirlpool Assembly, Evaportator
Schematic Location: 22
EscutcheonWPW10553630
Whirlpool Assembly, Fascia
Schematic Location: 25
Y
Ice Maker ComponentsW10577907
Whirlpool Assembly, Floor
Schematic Location: 24
Ice Maker ComponentsWPW10347093
Whirlpool Assembly, Ice Container
Schematic Location: 8
Skill level: - Fast and very easy fix
Y
WPW10492817
Whirlpool Assembly, Icebox (Foamed)
Schematic Location: 17
Y
Ice Maker, Ice Maker AssemblyWPW10764668
Whirlpool Assembly, Icemaker
Schematic Location: 1
Skill level: - Easy fix less than an hour
Y
InverterWPW10154805
Whirlpool Assembly, Inverter Box
Schematic Location: 11
Y
IndicatorW11290115
Whirlpool Assembly, Led
Schematic Location: 9
Skill level: - Easy fix less than an hour
Y
PadWPW10370592
Whirlpool Assembly, Pad (Black)
Schematic Location: 4
PadW11028219
Whirlpool Assembly, Pad (Cast Grey)
Schematic Location: 4
Y
PadW10853387
Whirlpool Assembly, Pad (Tempest Grey)
Schematic Location: 4
Y
P1KL6S1CS
Whirlpool Assembly, Produce Preserver
Schematic Location: 42
Y
Axle, Roller, Shaft WheelWPW10515763
Whirlpool Assembly, Roller (Left Hand)
Schematic Location: 19
Y
Axle, Roller, Shaft WheelWPW10515762
Whirlpool Assembly, Roller (Right Hand)
Schematic Location: 19
Skill level: - Easy fix less than an hour
Y
BoardW10789392
Whirlpool Assembly, User Interface (Black)
Schematic Location: 2
Y
BoardWPW10503833
Whirlpool Assembly, User Interface (Stainless Steel)
Schematic Location: 41
Y
Valve, Float AssemblyWPW10443217
Whirlpool Assembly, Valve Body
Schematic Location: 6
Y
Axle, Roller, Shaft Wheel67006434
Whirlpool Axle, Roller
Schematic Location: 28
Y
WPW10493169
Whirlpool Bin Upper
Schematic Location: 8
Y
BinW10858273
Whirlpool Bin, Secondary Mullion
Schematic Location: 33
Y
W10650427
Whirlpool Bin-freezr
Fan BladeWP67006337
Whirlpool Blad, Fan
Schematic Location: 11
Y
Fan BladeWP2188935
Whirlpool Blade, Fan
Schematic Location: 2
Y
WPW10344432
Whirlpool Block, Pivot
Schematic Location: 3
Y
BoardWPW10589837
Whirlpool Board, Control
Schematic Location: 5
Y
BoardW10870822
Whirlpool Board, Emitter Circuit
Schematic Location: 23
Y
ControlW10898445
Whirlpool Board, Receiver Circuit
Schematic Location: 18
Skill level: - Easy fix less than an hour
Y
Bracket, Flange, BladeW10391376
Whirlpool Bracker, Valve
Schematic Location: 17
Bracket, Flange, BladeW10434481
Whirlpool Bracket, Reservoir
Schematic Location: 27
Leg, Foot, CasterWPW10141622
Whirlpool Brake, Roller
Schematic Location: 8
Y
W10407187
Whirlpool Bumper, Door (Black)
Schematic Location: 10
Y
W10407188
Whirlpool Bumper, Door (Grey)
Schematic Location: 10
W10407175
Whirlpool Bumper, Door (White)
Schematic Location: 10
Y
AdhesiveWP4317852
Whirlpool Cement Alumilastic (1 1/4 Oz)Y
ClampWP3196256
Whirlpool Clamp, Power Cord
Schematic Location: 36
Clamp2185788
Whirlpool Clamp, Tube
Schematic Location: 31
ClipW10847834
Whirlpool Clip Retainer
Schematic Location: 4
Y
ClipW10852685
Whirlpool Clip Shaft
Schematic Location: 9
Y
ClipW10296661
Whirlpool Clip, Bottom Cover
Schematic Location: 32
ClipW10683556
Whirlpool Clip, Condenser
Schematic Location: 12
Clip67006338
Whirlpool Clip, Fan Motor
Schematic Location: 6
Clip10428101
Whirlpool Clip, Heater
Schematic Location: 23
ClipW10562834
Whirlpool Clip, Tube
Schematic Location: 17
Y
W10681408
Whirlpool Closer
SolenoidWPW10364560
Whirlpool Coil, 3 Way Valve
Schematic Location: 21
Y
WPW10277361
Whirlpool Collar, Gear
Schematic Location: 17
Y
Compressor - Sealed SystemW10276644
Whirlpool Compressor
Schematic Location: 26
Skill level: - Hard fix - you can do It
Y
CondensorW10559262
Whirlpool Condenser
Schematic Location: 16
Y
Power CordWPW10494227
Whirlpool Cord, Power
Schematic Location: 30
Y
Door,Remote Control DoorWPW10505294
Whirlpool Coupler, Door
Schematic Location: 33
Y
Cover,CapW10669663
Whirlpool Cover
Cover,CapW10278140
Whirlpool Cover, Bottom Unit
Schematic Location: 31
Y
Cover,CapW10518378
Whirlpool Cover, Connector
Schematic Location: 29
Cover,CapWPW10485658
Whirlpool Cover, Control Box
Schematic Location: 28
Cover,Cap67003485
Whirlpool Cover, Corner (Black
Schematic Location: 17
Y
WP12587703AP
Whirlpool Cover, Corner (Grey)
Schematic Location: 17
Cover,Cap12587703W
Whirlpool Cover, Corner (White)
Schematic Location: 17
FrameW10493545
Whirlpool Cover, Crisper
Schematic Location: 6
Cover,CapW10258502
Whirlpool Cover, Emitter)
Schematic Location: 21
Y
Cover,CapW10513424
Whirlpool Cover, Evaporator
Schematic Location: 4
Cover,CapW11188493
Whirlpool Cover, Evaporator
Schematic Location: 35
Y
Cover,CapW10284709
Whirlpool Cover, Gear (Left)
Schematic Location: 12
Y
Cover,CapW10294414
Whirlpool Cover, Gear (Right)
Schematic Location: 12
Y
Cover,CapWPW10598013
Whirlpool Cover, Icebox
Schematic Location: 16
Y
Cover,CapW10471617
Whirlpool Cover, Left Hinge (Black)
Schematic Location: 13
Cover,CapWPW10471618
Whirlpool Cover, Left Hinge (Grey)
Schematic Location: 13
Cover,CapW10471615
Whirlpool Cover, Left Hinge (White)
Schematic Location: 13
Cover,CapW10258510
Whirlpool Cover, Receiver
Schematic Location: 19
Y
Cover,CapW10407157
Whirlpool Cover, Right Hinge (Black)
Schematic Location: 12
Cover,CapWPW10407158
Whirlpool Cover, Right Hinge (Grey)
Schematic Location: 12
Y
Cover,CapW10248562
Whirlpool Cover, Right Hinge (White)
Schematic Location: 12
Cover,CapW10336736
Whirlpool Cover, Roller
Schematic Location: 16
Cover,CapW10518036
Whirlpool Cover, Side Adapter
Schematic Location: 36
Cover,Cap2215676
Whirlpool Cover, Terminal
Schematic Location: 37
Y
Cover,CapWPW10405166
Whirlpool Cover, Thermistor
Schematic Location: 17
Cover,CapW10438957
Whirlpool Cover, Thermistor
Schematic Location: 34
Cover,CapWPW10577369
Whirlpool Cover, Unit
Schematic Location: 30
Y
CrisperW10839369
Whirlpool Crisper, Medium
Schematic Location: 4
Y
CrisperW10509275
Whirlpool Crisper, Small
Schematic Location: 5
DamperWPW10248595
Whirlpool Damper, Electronic Control
Schematic Location: 33
Y
W10839397
Whirlpool Divider, Large Pantry
Schematic Location: 23
W10507444
Whirlpool Divider, Lower
Schematic Location: 10
Door,Remote Control DoorLW10547318
Whirlpool Door Freezer (Black)
Schematic Location: 1
Y
Door,Remote Control DoorLW10547320
Whirlpool Door Freezer (Stainless)
Schematic Location: 1
Y
Door,Remote Control DoorLW10547319
Whirlpool Door Freezer (White)
Schematic Location: 1
WPW10258520
Whirlpool Door, Emitter
Schematic Location: 27
Y
Cover,CapWPW10277949
Whirlpool Door, Filter Access
Schematic Location: 10
Y
Door,Remote Control DoorWPW10549589
Whirlpool Door, Ice
Schematic Location: 4
Door,Remote Control DoorLW10545986
Whirlpool Door, Left (Black)
Schematic Location: 1
Door,Remote Control DoorLW10503829
Whirlpool Door, Left (Stainless Steel)
Schematic Location: 1
Door,Remote Control DoorLW10545987
Whirlpool Door, Left (White)
Schematic Location: 1
Door,Remote Control DoorLW10546008
Whirlpool Door, Pantry (Black)
Schematic Location: 7
Y
Door,Remote Control DoorLW10550670
Whirlpool Door, Pantry (Stainless Steel)
Schematic Location: 7
Door,Remote Control DoorLW10546009
Whirlpool Door, Pantry (White)
Schematic Location: 7
Door,Remote Control DoorLW10545979
Whirlpool Door, Right (Black)
Schematic Location: 2
Door,Remote Control DoorLW10550669
Whirlpool Door, Right (Stainless Steel)
Schematic Location: 2
Door,Remote Control DoorLW10545980
Whirlpool Door, Right (White)
Schematic Location: 2
Compressor - Sealed SystemWPW10143759
Whirlpool Drier
Schematic Location: 25
Skill level: - Hard fix - you can do It
Y
Tray, Support , Ice Maker TrayWPW10606639
Whirlpool Drip Tray (Grey)
Schematic Location: 7
Tray, Support , Ice Maker TrayW10606644
Whirlpool Drip Tray (White)
Schematic Location: 7
HousingW10503486
Whirlpool Enclosure, Evaporator
Schematic Location: 18
Cover,CapW10811115
Whirlpool Enclosure, Valve
Schematic Location: 7
EvaporatorWPW10608485
Whirlpool Evaporator
Schematic Location: 20
Skill level: - Hard fix - you can do It
Y
Pipe, Tube, Hose, FittingW11084807
Whirlpool Extension, Drain
Schematic Location: 5
Skill level: - Easy fix less than an hour
Y
Insulation876370
Whirlpool Fiberglass Insulation (63 1/2`` X 35 1/2`` X 2 5/8``)
FilterW10311524
Whirlpool Filter, Air
Schematic Location: 12
Skill level: - Fast and very easy fix
Y
FilterEDR2RXD1
Whirlpool Filter, Water
Schematic Location: 11
Skill level: - Fast and very easy fix
Y
W10488124
Whirlpool Front, Upper Pan
Schematic Location: 12
Gasket , SealWPW10280988
Whirlpool Gaset, Rear Supply
Schematic Location: 38
Y
Gasket , SealW10505487
Whirlpool Gasket
Schematic Location: 4
Y
Gasket , SealW10491355
Whirlpool Gasket, Airdam
Schematic Location: 33
Y
Gasket , SealW10470981
Whirlpool Gasket, Damper
Schematic Location: 42
Y
Gasket , SealW10622442
Whirlpool Gasket, Door (Black)
Schematic Location: 30
Y
Gasket , SealW10846057
Whirlpool Gasket, Door (Grey)
Schematic Location: 30
Skill level: - Fast and very easy fix
Y
Gasket , SealW10622441
Whirlpool Gasket, Door (White)
Schematic Location: 30
Gasket , SealWPB8381501
Whirlpool Gasket, Drain
Schematic Location: 16
Gasket , SealW10510863
Whirlpool Gasket, Drain Tube
Schematic Location: 37
Gasket , SealW10668165
Whirlpool Gasket, Dual Evaporator
Schematic Location: 18
Gasket , SealWPW10392172
Whirlpool Gasket, Fan
Schematic Location: 40
Y
Gasket , SealW10856123
Whirlpool Gasket, Foam
Schematic Location: 2
Gasket , SealW10415341
Whirlpool Gasket, Hv Box
Schematic Location: 6
Y
Door,Remote Control DoorWPW10347087
Whirlpool Gasket, Ice Chute
Schematic Location: 25
Y
Gasket , SealW10347085
Whirlpool Gasket, Ice Door
Schematic Location: 16
Gasket , SealW10622445
Whirlpool Gasket, Pantry (Black)
Schematic Location: 8
Y
Gasket , SealW10622446
Whirlpool Gasket, Pantry (Grey)
Schematic Location: 8
Y
Gasket , SealW10622444
Whirlpool Gasket, Pantry (White)
Schematic Location: 8
Gasket , SealWPW10320706
Whirlpool Gasket, Rear Return
Schematic Location: 38
Y
DrawerW10277360
Whirlpool Gear, Spur
Schematic Location: 14
Shelf Support ComponentsWPW10493549
Whirlpool Glass, Crisper
Schematic Location: 31
Y
GreaseWP542638
Whirlpool Grease, Cilicone (1/2 Oz)Y
W10871842
Whirlpool Grille, Air (Freezer)
Schematic Location: 9
WPW10637669
Whirlpool Grille, Toe (Black)
Schematic Location: 22
WPW10637671
Whirlpool Grille, Toe (Grey)
Schematic Location: 22
Y
WPW10637668
Whirlpool Grille, Toe (White)
Schematic Location: 22
W10413009
Whirlpool Grommet, Air Return
Schematic Location: 15
67006339
Whirlpool Grommet, Fan Motor
Schematic Location: 12
Y
GuideW10577906
Whirlpool Guide, Crisper
Schematic Location: 22
GuideWPW10435760
Whirlpool Guide, Ice
Schematic Location: 6
Y
HandleW10830130
Whirlpool Handle, Door (Black)
Schematic Location: 8
Y
HandleW10719668
Whirlpool Handle, Door (Black)
Schematic Location: 37
Y
HandleW10827047
Whirlpool Handle, Door (Stainless Steel)
Schematic Location: 8
HandleW10827046
Whirlpool Handle, Door (Stainless Steel)
Schematic Location: 37
Skill level: - Easy fix less than an hour
Y
HandleW10830136
Whirlpool Handle, Door (White)
Schematic Location: 8
Y
HandleW10830089
Whirlpool Handle, Door (White)
Schematic Location: 37
Y
WireW10859326
Whirlpool Harness, Dual ValveY
WireW10837236
Whirlpool Harness, Evaporator Wire (Includeds Thermistor)Y
DrawerW11170612
Whirlpool Harness, Side Adapter
Schematic Location: 40
Skill level: - Medium fix difficulty
Y
WireW10746598
Whirlpool Harness, Unit
Schematic Location: 24
WireW10578603
Whirlpool Harns-wire
W10537691
Whirlpool Heater
WP12729128
Whirlpool Heater, Defrost
Schematic Location: 10
Y
HingeW10248705
Whirlpool Hinge, Center Left (Black)
Schematic Location: 24
HingeW10878115
Whirlpool Hinge, Center Left (Grey)
Schematic Location: 24
Y
HingeW10248434
Whirlpool Hinge, Center Left (White)
Schematic Location: 24
HingeW10248702
Whirlpool Hinge, Center Right (Black)
Schematic Location: 15
HingeW10407276
Whirlpool Hinge, Center Right (Grey)
Schematic Location: 15
HingeW10248433
Whirlpool Hinge, Center Right (White)
Schematic Location: 15
HingeW11218692
Whirlpool Hinge, Top (Left Hand)
Schematic Location: 10
Y
HingeWPW10248409
Whirlpool Hinge, Top (Right Hand)
Schematic Location: 10
HousingW11194438
Whirlpool Housing, Water Filter
Schematic Location: 6
Skill level: - Easy fix less than an hour
Y
InsulationWPW10280983
Whirlpool Insulation
Schematic Location: 28
Y
Insulation876029
Whirlpool Kit, Foam Slab (30`` X 32 1/2`` X 1 1/2``)
WPW10248516
Whirlpool Ladder, Center
Schematic Location: 19
WPW10372170
Whirlpool Ladder, Side
Schematic Location: 16
LatchWP2223877
Whirlpool Latch, Push
Schematic Location: 9
Y
Cover,CapW10277839
Whirlpool Lid, Hv
Schematic Location: 39
Y
Pump, MotorW10822606
Whirlpool Motor Dispenser
Schematic Location: 6
Skill level: - Easy fix less than an hour
Y
Pump, MotorWPW10514110
Whirlpool Motor, Evaporator (Includes Harness, Thermistor, And Defrost Thermostat)
Schematic Location: 13
Y
PlateWPW10393265
Whirlpool Nameplate (Grey)
Schematic Location: 11
PlateWPW10391355
Whirlpool Nameplate (White)
Schematic Location: 11
4392899
Whirlpool Paint (1/2 Oz Biscuit / Bisque)
Skill level: - Fast and very easy fix
Y
285006
Whirlpool Paint (12 Oz Enamel Black)Y
350930
Whirlpool Paint (12 Oz White)Y
4392901
Whirlpool Paint (12 Oz. Biscuit/bisque)Y
Auto Primer350942
Whirlpool Paint (12 Oz. White Primer)Y
799344
Whirlpool Paint Bulk (1 Qt. White)
72032
Whirlpool Paint, Touch Up (1/2 Oz Black)Y
Washer72017
Whirlpool Paint, Touch Up (1/2 Oz White )
Skill level: - Fast and very easy fix
Y
511873
Whirlpool Paint, Touch Up (1/2 Oz White Porcelain)Y
WPW10485096
Whirlpool Pan Stop (Left)
Schematic Location: 16
Y
WPW10485089
Whirlpool Pan Stop (Right)
Schematic Location: 16
Y
BurnerW10836964
Whirlpool Pan, Drain
Schematic Location: 19
WPW10530656
Whirlpool Pan, Pantry
Schematic Location: 18
Door,Remote Control DoorWP2198634
Whirlpool Pin, Door
Schematic Location: 29
Y
PlateW10570074
Whirlpool Plate
PlateW10837274
Whirlpool Plate, Ice Chute
Schematic Location: 2
Y
CabinetWPA3076901
Whirlpool Plug Button (Black)
Schematic Location: 7
RailW10698202
Whirlpool Rail-mulln
RailW10698203
Whirlpool Rail-mullnY
SlideW11025614
Whirlpool Rail-mullnY
RailW10698206
Whirlpool Rail-mulln
W11225849
Whirlpool RetainerY
W10212137
Whirlpool Retainer, Door
Schematic Location: 34
FastenerWPW10400825
Whirlpool Retainer, Ice Chute
Schematic Location: 24
Y
TrimW10462439
Whirlpool Ring, Trim (Black)
Schematic Location: 8
TrimWPW10402180
Whirlpool Ring, Trim (Chrome)
Schematic Location: 8
Y
TrimW10462438
Whirlpool Ring, Trim (White)
Schematic Location: 8
Axle, Roller, Shaft WheelWP67005149
Whirlpool Roller
Schematic Location: 13
Y
ScrewWP8281196
Whirlpool Screw
Schematic Location: 9
Skill level: - Fast and very easy fix
Y
Screw67006564
Whirlpool Screw
Schematic Location: 20
ScrewWP33001882
Whirlpool Screw
Schematic Location: 21
ScrewM0202321
Whirlpool Screw
Schematic Location: 23
ScrewWPW10141645
Whirlpool Screw
Schematic Location: 25
Screw67006425
Whirlpool Screw
Schematic Location: 26
Y
ScrewW10854958
Whirlpool Screw
Schematic Location: 38
Y
ScrewWP98165
Whirlpool Screw
Schematic Location: 8
Y
ScrewWP67006908
Whirlpool Screw
Schematic Location: 15
Y
ScrewWPW10464016
Whirlpool Screw
Schematic Location: 3
ScrewWPM0238331
Whirlpool Screw
Schematic Location: 7
HandleWPW10661886
Whirlpool Screw
Schematic Location: 12
Skill level: - Easy fix less than an hour
Y
ScrewWPW10141625
Whirlpool Screw
Schematic Location: 1
ScrewW10709798
Whirlpool Screw
Schematic Location: 14
Screw8281232
Whirlpool Screw
Schematic Location: 27
Screw12991702
Whirlpool Screw
Schematic Location: 13
Screw67006692
Whirlpool Screw
Schematic Location: 20
ScrewW10423560
Whirlpool Screw
Schematic Location: 21
ScrewWPW10272364
Whirlpool Screw
Schematic Location: 1
Y
ScrewW10421495
Whirlpool Screw
ScrewW10403211
Whirlpool Screw (Black)
Schematic Location: 11
ScrewWPW10308751
Whirlpool Screw (Black)
Schematic Location: 14
Y
ScrewW11177651
Whirlpool Screw (Grey)
Schematic Location: 11
ScrewWP3400065
Whirlpool Screw (Stainless)
Schematic Location: 20
Y
ScrewWP489443
Whirlpool Screw (Stainless)
Schematic Location: 13
ScrewWP8281163
Whirlpool Screw (Stainless)
Schematic Location: 7
ScrewW10403208
Whirlpool Screw (White)
Schematic Location: 11
ScrewW10216919
Whirlpool Screw, Shoulder
Schematic Location: 9
WPM0500703
Whirlpool Seal
Schematic Location: 15
DispenserWP2198628
Whirlpool Seal
Schematic Location: 3
Skill level: - Fast and very easy fix
Y
WP503695
Whirlpool Sealer CorkY
212643
Whirlpool Sealer Gum (4 Feet)Y
WP505587
Whirlpool Sealer Mastic (1Qt)Y
ShaftWPW10503522
Whirlpool Shaft
Schematic Location: 4
Y
ShaftWPW10347114
Whirlpool Shaft Motor
Schematic Location: 5
ShaftW10298176
Whirlpool Shaft, Rack
Schematic Location: 15
Shelf Support ComponentsWPW10709163
Whirlpool Shelf, Fixed
Schematic Location: 9
Y
Glass ShelfWPW10709175
Whirlpool Shelf, Tuck
Schematic Location: 1
Y
WPW10406719
Whirlpool Shroud
Schematic Location: 29
Y
WPW10363507
Whirlpool Shroud, Evaporator Fan
Schematic Location: 10
Sleeve2162499
Whirlpool Sleeve
Schematic Location: 7
SlideW10258540
Whirlpool Slide, Icemaker Shut Off
Schematic Location: 22
SpringWP2198635
Whirlpool Spring Door
Schematic Location: 28
Skill level: - Easy fix less than an hour
Y
Cleaner31462A
Whirlpool Stainless Steel Cleaner
StrapW10236396
Whirlpool Strap, Compressor
Schematic Location: 36
Y
WPW10453401
Whirlpool Supply Power
Schematic Location: 2
Y
WPW10306786
Whirlpool Supply, Power Led
Schematic Location: 27
Y
W11230117
Whirlpool Support, Damper
Schematic Location: 32
Y
WPW10389152
Whirlpool Support, Fan
Schematic Location: 29
Y
WPW10236512
Whirlpool Support, Front
Schematic Location: 43
W10469177
Whirlpool Support, Pan
Schematic Location: 11
WPW10248967
Whirlpool Support, Rear
Schematic Location: 30
Y
Switch12002646
Whirlpool Switch, Light
Schematic Location: 29
Skill level: - Easy fix less than an hour
SwitchWPC3680310
Whirlpool Switch, Light
Schematic Location: 7
Skill level: - Easy fix less than an hour
Tape479502
Whirlpool Tape, Vinyl (3/4 X 108``)
Terminal833938
Whirlpool TerminalY
Sensor, Thermistor, ThermostatW11168403
Whirlpool Thermistor
Schematic Location: 28
Y
WP1117510
Whirlpool Torx Screw Wrench, Torx Key
Skill level: - Medium fix difficulty
Y
Tray, Support , Ice Maker TrayW10342573
Whirlpool Tray, Drip
Schematic Location: 18
TrimW10505516
Whirlpool Trim, Icebox
Schematic Location: 20
Shelf Support ComponentsW10846358
Whirlpool TrivetY
Pipe, Tube, Hose, FittingW10503562
Whirlpool Tube, Drain
Schematic Location: 32
Y
Pipe, Tube, Hose, FittingW10815476
Whirlpool Tube, Fill
Schematic Location: 3
Y
Pipe, Tube, Hose, FittingWPW10499015
Whirlpool Tube, Water
Schematic Location: 31
Y
Valve, Float Assembly978029
Whirlpool Valve, Access
Valve, Float Assembly978030
Whirlpool Valve, Access
Valve, Float AssemblyWP978025
Whirlpool Valve, AccessY
Valve, Float Assembly978026
Whirlpool Valve, AccessY
Valve, Float Assembly978027
Whirlpool Valve, AccessY
Valve, Float Assembly876764
Whirlpool Valve, AccessY
Valve, Float AssemblyWPW10341329
Whirlpool Valve, Dual Water
Schematic Location: 5
Skill level: - Easy fix less than an hour
Y
Valve, Float AssemblyW10865826
Whirlpool Valve, Water
Schematic Location: 18
Skill level: - Easy fix less than an hour
Y
ShieldW10606658
Whirlpool Wall Dispenser False (White)
Schematic Location: 3
ShieldW10606648
Whirlpool Wall, Dispenser False (Grey)
Schematic Location: 3
Pipe, Tube, Hose, FittingWPW10674102
Whirlpool Water Line, Valve To Hinge
Schematic Location: 13
Whirlpool Corporation is the number one major appliance manufacturer in the world, and includes brands such as Whirlpool, KitchenAid, Maytag, Consul, Brastemp, Amana, Bauknecht, Jenn-Air, Indesit, among others. The Whirlpool Corporation is an American multinational manufacturer and marketer of home appliances, headquartered in Benton Charter Township, Michigan, United States, near Benton Harbor, Michigan. In many Whirlpool appliances, remarkable sense and adapt technology responds to the needs of your clothes, your meals and your foods. By adapting to each situation, intuitive sensors make key refinementsprecisely adjusting water levels for the best clean possible or measuring moisture content for better baking. So your fabrics look newer longer, meals cook more evenly, and foods stay cool and flavorful.
